Winsmith Launches New Line of Helical Inline and Bevel Gearboxes
SPRINGVILLE, NY, August 5, 2025 – Winsmith (https://www.winsmith.com/), manufacturer of custom, highly-engineered gearing solutions, has announced the launch a new line of Helical Inline and Helical Bevel Gearboxes.
Winsmith Helical Inline Gearbox (HXI) and Winsmith Helical Bevel Gearbox (HXB) feature a modular design with single-piece housing units. These gearboxes are built to order and can be assembled with various accessory options. Winsmith can ship this stocked inventory from our Asheville, NC gearing facility within 1 to 3 days.
“Our Winsmith Helical Inline Gearbox is designed with full modularity and includes a NEMA C flange to optimize installation space while enhancing performance,” said Crad Winkelvoss, Winsmith vice president/general manager. “These modular, compact Helical Gearboxes contain efficient drive systems designed for a variety of applications.”
Specifications Summary
| HXI | HXB | |
|---|---|---|
| Available Sizes | 6 | 8 |
| 2-Stage Ratio Ranges | 3.52 to 61.89 | 6.03 to 74.81 |
| 3-Stage Ratio Ranges | 38.4 to 480.16 | 36.17 to 589.85 |
| Input Power (hp) | 1/4 to 5 (HP) | 1/4 to 10 |
| Output Torque (ibf-in) | 1460 to 4550 | 797 to 3629 |
Available gearbox accessories include mounting feet, output flanges and reaction (torque) arms.
Winsmith high-efficiency, right-angle gearing benefits include:
- Precision ground and hardened gears providing optimal durability and efficiency for a long operating life, low noise and minimal energy losses.
- Single-piece aluminum housing design which provides corrosion protection and helps eliminate the risk of leaks. A secondary finish is not required but these units can accommodate paint for aesthetic purposes.
- Precision machining guarantees the proper alignment of bearings and gears for optimal operation and reliability.
- Features a removable inspection cover that facilitates regular gear inspections during maintenance for optimal performance over time.
More product details can be found on our – website product pages (HXI and HXB). Products are available to order now. Contact your local Winsmith sales representative for more information.
Founded in 1901, Winsmith has built gearing solutions with a reputation for high quality, reliability and first-class customer service.
About Winsmith
Founded in 1901, Winsmith (www.winsmith.com) produces custom reliable, high-quality solutions with millions of product configurations at US facilities in Springville, NY, Flowery Branch, GA and Asheville, NC. Winsmith designs and creates gearboxes to exceed the highest industry standards with our exceptional team of engineers, technicians and experts who drive our mission to deliver gearing solutions. Winsmith is a business of HBD Industries, Inc.
